COMPACT 1.4
Take care not to invert the polarities when connecting the unit to the battery. If this happens, the control
plate does not come on and the unit does not work.
Blower
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Compressor
electronic
module

IMPORTANT WARNING!

TEMP
Wiring strip
Na
Electronic
module
10 A. Fuse
-
+
+
25 A. Fuse
F
D
C
P
T
Compressor
Air conditioning for vehicles
ºC
ºF
ON/OFF
Battery
25
EN

Electric wiring

Temperature probe
Fan
Compressor
electronic
module
-
+
+
F
D
C
P
T
Compressor
