• The clear-Teflon moisture shield on the microphone
prevents perspiration or makeup from clogging the
sound entry ports and thus changing the sound and re-
ducing the microphone's sensitivity.
Therefore, never remove the moisture shield from the
microphone!
• The behind-the-neck headband and microphone arm
are made of thin-walled tubing. Bend these parts with
extreme caution. If you bend the parts too sharply they
may break, which will void the warranty.
1, 2, 3
5
As delivered, the microphone arm is fitted on the right side of
the behind-the-neck headband. To mount the microphone arm
on the left side of the headband:
1. Pull the microphone arm holder (2) with the microphone arm
(3) from the temple piece (1) in the direction of the arrow.
2. Remove the cover (4) from the opposite temple piece.
3. Remove the cable from the cable holder (5).
4. Slide the microphone arm holder (2) and cover (4) into the
wire loops below the respective opposite temple pieces (1)
to the point that they lock into place.
AKG HC 577 L

4 Using Your Microphone

4
L
I I m m p p o o r r t t a a n n t t ! !
4 4 . . 1 1 M M o o u u n n t t i i n n g g t t h h e e
M M i i c c r r o o p p h h o o n n e e A A r r m m o o n n
t t h h e e L L e e f f t t o o r r R R i i g g h h t t
5b
Fig. 3: Removing the
microphone arm and
mounting it on the op-
posite temple piece.
Refer to fig. 3/1, 2, 3.
Refer to fig. 3/4.
