Parameters
Exposure Level
Minimum Shutter
Maximum Shutter
IR-CUT Latency
IR-CUT
IR LED
Color Mode
Schedule Mode

On Screen Display(OSD)

Parameters
Video Stream
Font Size
Tabelle 4-4-4 Beschreibung der Tasten
Level 0~10 are available to meet your need
Minimum Shutter is the same as Maximum Exposure Time. Set the minimum
s
Shutter to 1~1/100000
Maximum Shutter is the same as Minimum Exposure Time. Set the maximum
s
Shutter to 1~1/100000
The interval time of switching one mode to another
Turn on or turn off IR-CUT
Turn on or turn off IR-LED
Select B/W or Color mode under Day/Night mode
Here you can customize your special demands for different time, then the Day
mode and Night mode will switch automatically according to your settings
Abbildung 4-4-13 OSD
Tabelle 4-4-5 Beschreibung der Tasten
Enable to set OSD for primary stream and secondary stream
Smallest/Small/Medium/Large/Largest/Auto are available for title and date
Function Introduction
Function Introduction
41
