Milesight MS-C2181-PA Benutzerhandbuch Seite 44

Single Mode
Day/Night Mode
Schedule Mode
BLC Region
Wide Dynamic Range
Wide Dynamic Level
Anti-flicker Level
High Light Compensation
HLC Level
Day Enhancement Mode
Night Enhancement Mode
Schedule Setting
Hinweis:
1) Sie können den Zeitplan anpassen, um die Weißabgleich-Modi zu aktivieren / deaktivieren.
environment automatically;
Manual Mode: The camera will adjust the brightness according to the
value you set, you can set the exposure time from 1~1/100000
the value is, the brighter the image is;
Schedule Mode: You can customize the schedule to enable/disable Auto
Mode and Manual Mode.
Set single mode for BLC/WDR/HLC.
Support BLC/WDR/HLC on Day Enhancement Mode/Night Enhancement
Mode separately.
Set schedule mode for BLC/WDR/HLC.
Off, Customize, and Centre are available (in single mode, only enable when
WDR is disable)
Off: Calculate the full range of view and offer appropriate light
compensation
Customize: This option enables you to customize inclusive or exclusive
region manually
Centre: This option will automatically add an inclusive region in the middle
of the window and give the necessary light compensation
This function which can capture and display both bright and dark areas in
the same frame enables details of objects in both bright and dark areas to
be visible.
Off: Disable WDR function
On: Enable the WDR, there are Low/High/Auto three levels
Customize: Customize the schedule to enable/disable the WDR function
and set the levels with Low/High/Auto
Set WDR with Low/High/Auto level
Reduce flickers that appear on screen in some lighting conditions and there
are 10 levels of anti-flicker adjustments
This function is only for H.265 series to adjust the brightness to a normal
range when the light is strong, refers to Figure 4-4-11
Off: Disable HLC function
General Mode: Enable the general mode of HLC, and there is a setting for
HLC Level
Enhanced Mode: Enable the enhanced mode of HLC, and there is a setting
for HLC Level
Select level for HLC
BLC/WDR/HLC are available.
BLC/WDR/HLC are available.
Customize the schedule to enable/disable BLC/WDR/HLC mode
s, t he higher
38
