MICO 40-50-ST
MiCO 50
Position
This function enables you to center the display vertically and horizontally.
1 Press " " or "
t u
2 Press " " or "
t u
note
•
This function is only available for Component and
Y/C Delay
The function allows you to adjust color and luma signals in order to match both timings up. It is only available for
Composite and S-Video.
Orientation
This projector is equipped with a reverse/invert image function that allows you to reverse or invert the projected image
for various applications.
Selection
Floor
Ceiling
Floor Rear
Ceiling Rear Reversed and inverted image
note
•
This function is used for the reversed image and
Frequency
The function enables you to adjust vertical noise (only available for Component and Graphics RGB inputs).
Phase
The function enables you to adjust horizontal noise (similar to tracking on your VCR). It is only available for Component
and Graphics RGB inputs.
Execute Auto Tune
The function allows you to perform auto tune (only available for RGB Graphics).
Auto Tune
The function allows you to adjust a computer image automatically (only available for RGB Graphics).
" of the Horizontal Position, the display will move to the left or the right.
" of the Vertical Position, the display will move upward or downward.
Description
Normal image
Inverted image
Reversed image
Graphics RGB inputs.
ceiling-mount setups.
23
