Specifications - ASROCK K7VT4A Pro Schnellinstallationsanleitung

1.2 1.2 1.2

Specifications

Specifications Specifications
1.2 1.2 Specifications Specifications
Platform: ATX Form Factor: 12.0-in x 7.0-in, 30.5 cm x 17.8 cm
CPU: Supports Socket A (462 pins) for
AMD Athlon
Chipsets: North Bridge:
VIA KT400A, FSB@200 / 266 / 333 MHz
South Bridge:
VIA VT8237, Supports USB 2.0, ATA 133, SATA 1.5Gb/s
Memory: 2 DDR DIMM slots: DDR1and DDR2
PC2100 (DDR266) / PC2700 (DDR333)
for 2 DDR DIMM slots, Max. 2GB;
PC3200 (DDR400) for 1 DDR DIMM slot, Max. 1GB
IDE: IDE1: ATA 133 / Ultra DMA Mode 6
IDE2: ATA 133 / Ultra DMA Mode 6
Supports up to 4 IDE Devices
Serial ATA: 2 SATA Connectors, Support 1.5Gb/s Data Transfer Rate
Floppy Port: Supports up to 2 Floppy Disk Drives
Audio: 5.1 Channels AC'97 Audio
LAN: Speed: 802.3u (10/100 Ethernet), Supports Wake-On-LAN
Hardware Monitor: CPU Temperature Sensing
Motherboard Temperature Sensing
CPU Overheat Shutdown to Protect CPU Life
(ASRock U-COP)(see CAUTION 1)
CPU Fan Tachometer
Chassis Fan Tachometer
Voltage Monitoring: +12V, +5V, +3.3V, Vcore
PCI slots: 5 Slots with PCI Specification 2.2
AGP slot: 1 AGP Slot, Supports 1.5V, 8X/4X AGP Card (see CAUTION 2)
USB 2.0: 8 USB 2.0 ports:
include 6 ready-to-use USB 2.0 ports on the rear panel,
plus one on-board header supporting 2 extra USB 2.0 ports
(see CAUTION 3)
TM
ASRock I/O Plus : 1 PS/2 Mouse Port, 1 PS/2 Keyboard Port,
1 Serial Port: COM1,
1 Parallel Port (ECP/EPP Support)
6 ready-to-use USB 2.0 Ports,
1 RJ-45 Port,
Audio Jack: Line In / Line Out / Microphone
ASRock K7VT4A Pro Motherboard
TM / Athlon TM XP / Duron TM / Sempron TM processor
5 5 5 5 5
