LINE REPLACEMENT
EN
NOTICE: Always use standard 2mm diameter nylon cutting line. Using line other than
that specified may cause the string trimmer to overheat or become damaged.
WARNING:
Never use metal-reinforced line, wire, rope, etc. These can break off
and become dangerous projectiles.
There are two methods to replace the cutting line:
1. Wind the spool with new line.
2. Install a pre-wound spool.
Wind the spool with new line
WARNING:
To prevent serious personal injury, remove the battery pack from the
tool before servicing, cleaning, changing attachments or removing material from the unit.
1. Press the release tabs on the spool
base and remove the spool retainer
by pulling it straight out (Fig. 20).
2. Remove the spool. Use a clean cloth
to clean the inner surface of the
spool retainer and spool base.
NOTICE: Always clean the spool retainer,
spool and spool base before reassembling
the trimmer head.
3. Check the spool retainer, spool and
spool base for wear. If necessary,
replace the wear parts.
4. Take approximately 6m of new
cutting line. Fold the line in half
and then adjust it so that one end
is 11cm longer than the other end
(Fig. 21).
26
56V LITHIUM-ION CORDLESS STRING TRIMMER — ST1210E
20
Tab
21
11 cm
5. Hook the folded end of the cutting
line onto either of the slots in the
spool (Fig. 22).
6. Wind the line, in two even and tight
layers, onto the spool. Wind the line
in the direction indicated on the
spool (Fig. 22).
NOTICE: Failure to wind the line in the
direction indicated will cause the trimmer
head to operate incorrectly.
7. Place the ends of the line in two
opposite notches in the spool, with
approximately 15 cm protruding
(Fig. 23).
8. Align the notches of the spool from
which the lines protrude with the
eyelets in the spool retainer and
position the spool in the retainer
(Fig. 24).
56V LITHIUM-ION CORDLESS STRING TRIMMER — ST1210E
22
Wind Direction
23
15 cm
24
Notch
Notch
Eyelet
Eyelet
27
EN
