6.3 Switching the sound on/off
(Fig. 3 Item 4 B)
To switch the sound on or off , press the button (B)
and keep it pressed for about 1 second
6.4 Menu (Fig. 3 Item 4 C)
You can use the menu to switch between the indi-
vidual functions.
•
To go to the menu, press the C button.
•
Then keep pressing the C button until you
have marked the function you require.
•
To confirm the function you require, press the
A button.
6.5 Setting the unit of measurement
(Fig. 3 Item 4 G)
The default unit of measurement is the metric
meter (m). But you can also select from three
other unit settings. To do so, press the G button
and keep it pressed until the unit changes. Keep
repeating until the unit you require is displayed.
6.6 Setting the reference point (Fig. 4)
Measurements can be performed from 3 diff erent
reference points on the equipment. To do so,
press the G button briefl y and select the reference
point you require.
•
Front edge reference point (see Fig. 4a)
•
Rear edge reference point (see Fig. 4a)
•
Swing-out stop reference point (see Fig. 4b)
The reference point can be selected in any func-
tion.
6.7 Using the measurement functions
Note
The laser beam switches off automatically after
completion of each measurement. Press the ON/
Measuring button.
6.7.1 Function: "Measure single distance"
„Symbol „ (Fig. 5)
Procedure:
•
Press button A once
•
Switch on the equipment
•
Press buttons C + A: Call up the menu and
select a function (see 6.4)
•
Press button G if necessary: Select the refe-
rence point on the equipment (see 6.6)
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure
→ The result is displayed at the bottom in m
Anl_TE_LD_60_SPK9.indb 22 Anl_TE_LD_60_SPK9.indb 22
GB
6.7.2 Function: "Measure areas"
„Symbol " (Fig. 6)
Procedure:
•
Press button A once:
•
Switch on the equipment
•
Press buttons C + A: Call up the menu and
select a function (see 6.4)
•
Press button G if necessary: Select the refe-
rence point on the equipment (see 6.6)
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the area length
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the area width
→ The result is displayed at the bottom in m²
6.7.3 Function: "Measure volume"
„Symbol " (Fig. 7)
Procedure:
•
Press button A once:
Switch on the equipment
•
Press buttons C + A: Call up the menu and
select a function (see 6.4)
•
Press button G if necessary: Select the refe-
rence point on the equipment (see 6.6)
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the room
length
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the room
height
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the room width
→ The result is displayed at the bottom in m³
6.7.4 Function: "Measure two adjacent areas"
„Symbol " (Fig. 8)
Procedure:
•
Press button A once:
Switch on the equipment
•
Press buttons C + A: Call up the menu and
select a function (see 6.4)
•
Press button G if necessary: Select the refe-
rence point on the equipment (see 6.6)
•
Press button A once: Switch on the laser
•
Align the laser
