Explanation of specialist terms:
Motor speed ("Throttle"): This controls the rotati-
onal speed of the motor. Stick forward = maximum
speed; stick back = motor off.
Rudder: This controls the model's attitude around
the vertical (yaw) axis, causing the aeroplane to fly
to the right or left.
Up-elevator / down-elevator: This controls the
model's flight attitude around the lateral (pitch)
axis. Stick forward = the model descends; stick
back = the model climbs.
Ailerons: This controls the model's flight attitude
around the longitudinal (roll) axis. Stick right = right
wing down; stick left = left wing down.
Mode 1: Function assignment of the control move-
ments relative to the stick movements.
In this case throttle and ailerons are controlled by
the right-hand transmitter stick, elevator and rudder
by the left-hand stick.
Mode 2: Function assignment of the control move-
ments relative to the stick movements.
In this case throttle and rudder are controlled by
the left-hand transmitter stick, elevator and ailerons
by the right-hand stick.
Dual-Rates:
Switchable travel reduction for control movements.
Operating instructions - ARCUS E-RISE 500 RTF 2.4 GHz No. 2562
Contents
Explanation of specialist terms / Contents
Safety Notes
Set contents / Specification
Assembling the model
Charging the flight battery / LiPo battery safety notes
Summary of transmitter settings in Mode 1 und Mode 2
Primary and expanded control functions / converting the transmitter 10
Transmitter settings in Mode 1
Transmitter settings in Mode 2
Flight preparation
Controlling the model
Important notes
Re-binding the transmitter
Replacement parts list
Notes
General notes
Page
3
4, 5
6
7
8
9
11
12
13
14
15
16
17
18
19
3
