3. Layout, Connections & Jumper Settings
3.2 Connections
USB 2.0 A-Port:
USB 2.0 B-Port:

3.3 Jumper Settings

The EX-1178S will be delivered with the setting Bus-Power.
ity to cut the power at the data line.
both sides. Then you must set the jumper JP1 from BUS (Bus-Power) to SLF (Self-
Power). See the following picture.
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
USB 2.0 A-Port
Pin
1
2
USB 2.0 B-Port
Pin
1
2
For this you open the case with the four screws on
BUS
SLF
JP1
10
Signal Pin
VCC 3
DATA- 4
Signal Pin
VCC 3
DATA- 4
But you have the possibil-
EX-1178S
Signal
DATA+
GND
Signal
DATA+
GND
