direction. The cutting angle of the teeth
must point in running direction, i.e. for-
wards (see the arrow on the blade guard).
•
Refit and set the splitter (2) and the saw blade
guard (4) (see 6.2., 6.3.)
•
Check to make sure that all safety devices
are properly mounted and in good working
condition before you begin working with the
saw again.

7. Operation

7.1. ON/OFF switch and overload switch
(Fig. 7)
•
To turn the saw on, press the green button
„I". Wait for the blade to reach its maximum
speed of rotation before commencing with
the cut.
•
To turn the equipment off again, press the red
button „0".
The motor of this equipment is protected against
overload by an overload switch (46). If the rated
current is exceeded, the overload switch (46) will
shut down the equipment.
•
Let the equipment cool down for several mi-
nutes.
•
Press the overload switch.
•
Press the green button „I" to switch on the
equipment.
7.2. Cutting depth (Fig. 1)
Turn the hand crank (13) to set the blade (5) to
the required cutting depth.
Turn anti-clockwise:
smaller cutting depth
Turn clockwise:
larger cutting depth
7.3. Parallel stop
7.3.1. Stop height (Fig. 21, 22)
•
Push the stop rail (6) onto the parallel stop (7)
•
The parallel stop (7) supplied with the bench-
type circular saw has two different guide
faces.
•
For thick material you must use the stop rail
(6) as shown in Fig. 21, for thin material you
must use the stop rail as shown in Fig. 25.
•
To change over the stop rail (6) you have to
slacken the two knurled screws (w) in order to
Anl_TE_CC_1825_U_SPK7.indb 30 Anl_TE_CC_1825_U_SPK7.indb 30
GB
disconnect the stop rail (6) from the parallel
stop (7).
•
Depending on the required cutting height, the
stop rail can be slid into two different grooves
on the parallel stop and secured with the
knurled screws.
•
The stop rail can be taken off and fastened to
either the right or left parallel stop depending
on the purpose.
•
The parallel stop is set at right-angles to the
guide rail at the factory. It can be readjusted
using two Allen screws (in the parallel stop).
•
If you need to readjust the parallel stop: Sla-
cken the screws (u) on the parallel stop (7).
Adjust the parallel stop so that it is parallel to
the saw blade (5) or vertical to the guide rail
(9). Retighten the screws (u).
7.3.2. Cutting width (Fig. 1, 21, 22)
•
The parallel stop (7) has to be used when
making longitudinal cuts in wooden workpi-
eces.
•
The parallel stop (7) can be mounted on eit-
her side of the saw table (1).
•
The parallel stop (7) has to be mounted in the
guide rail (9) of the saw table (1).
•
The parallel stop (7) can be set to the requi-
red dimension with the help of the scale (47)
on the guide rail (1).
•
You can clamp the parallel stop in the requi-
red position by pressing the lever (11).
7.3.3. Table width extension left/right and sca-
le (Fig. 6a, 6b, 23-26)
•
To pull out the left table width extension (8),
open the locking buttons (24) at the front and
rear on the bottom side of the table. Then pull
the table width extension to the left and secu-
re the locking buttons again.
•
To pull out the right table width extension
(10), open the locking buttons (25) at the front
and rear on the bottom side of the table. Then
pull the table width extension to the right and
secure the locking buttons again.
•
The right table width extension has a traveling
scale indicator. The scale has a total of four
different readings for the high and low adjust-
ment of the parallel stop (see 7.3.1), each
with a retracted and extended table.
•
With the right table width extension retracted,
the width set at the parallel stop can be read
off the lower scale row. It is indicated by the
pointer (a) of the stop rail. The lower scale
row has two lines, marked for the high and
low setting of the parallel stop (see 7.3.1)
