Important!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.

1. Safety regulations

The corresponding safety information can be
found in the enclosed booklet.
Caution!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.

2. Layout and items supplied

2.1 Layout (Fig. 1-9)
1. Saw table
2. Splitter
3. Cover for extractor connection
4. Saw blade guard
5. Saw blade
6. Stop rail (parallel stop)
7. Parallel stop
8. Width extension, left
9. Guide rail for parallel stop
10. Width extension, right
11. Clamp lever for parallel stop
12. Scale for saw blade angle
13. Adjustment lever for cutting height
14. Setting wheel for saw blade angle
15. Setting screw
16. Leg
17. Rubber foot (type A)
18. Cross strut, bent type
19. Plate
20. Cross strut, straight type
21. Rubber foot (type B)
22. Adjustment lever 45° - 47°
23. Adjustment lever -2° - 0°
24. Locking button for table width extension, left
Anl_TE_CC_1825_U_SPK7.indb 26 Anl_TE_CC_1825_U_SPK7.indb 26
GB
25. Locking lever for table width extension, right
26. Transport handle
27. Stop rail for angle stop
28. Angle stop
29. Push stick
30. Key for changing the saw blade
31. Open-ended spanner 10 mm / 13 mm
32. Hex screw, short
33. Hex screw, medium
34. Hex screw, long
35. Washer
36. Self-locking nut
37. Slide
38. Locking lever for slide
39. Wheel
40. Axle
41. Axle holder
42. Extractor connection (housing)
43. Table insert
44. Locking lever for saw blade angle
45. On/Off switch
46. Overload switch
47. Scale
48. Groove
49. Locking grip
50. Locking button
51. Nut, fl at
2.2 Items supplied
Please check that the article is complete as spe-
cifi ed in the scope of delivery. If parts are missing,
please contact our service center or the nearest
branch of the DIY store where you made your
purchase at the latest within 5 work days after
purchasing the article and upon presentation of
a valid bill of purchase. Also, refer to the warranty
table in the warranty provisions at the end of the
operating instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Important!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
