BabyGo Iso 360 Bedienungsanleitung Seite 22

5 INSTALLATION
5.1 Installation of the child restraint system
Step 1: Install ISOFIX guide sleeves to ISOFIX lower anchorages.
Step 2: Press down the red button to adjust ISOFIX attachment of both sides to
the longest. Then put the ISOFIX attachments into guide sleeves, and insert them
into ISOFIX anchorages. Make sure that you have heared a "click" and the ISOFIX
latching indication shows GREEN. Next, you can push the child seat towards the
car seat backrest until it is firmly pressed against the car seat backrest. If you want
to release the ISOFIX attachments, just need to press the ISOFIX red button. Then
adjust the support leg to touch the ground completely (see 4.5).
5.2 Installation of the child
1. Loosen the harness (see 4.3), and
place the child on the child seat.
2. Adjust the height of headrest
(see(4.4).
3. Tighten the harness(see 4.3).
Installation status
IMPORTANT:
1. Do not place the child seat in this
position when the car is moving.
2. You should turn it to the driving
status after installation of child.
22
Group I (9-18kg)
IMPORTANT:
Not to use forward-facing before
the child's weight exceeds 9kg.
Car Seat + Isofix
Group 0+ (0-13kg)
Driving status
