17. GND (black) (control unit)
18. Power cable plug (control unit)
19. Buzzer
20. Sensors
21. Control unit
IMPORTANT:
1. when connecting the sensors to the control unit, keep
in mind that sensor that will be located on the left side
of the vehicle must be connected to socket marked as A
or B; while sensor on the right side of the vehicle must
be connected to socket marked as C or D. Such way
of connection guarantees proper display of obstacle's
position on the screen.
2. If the sensors have been connected properly, the buzzer
will issue a short sound signal, which means proper
operation.
Note: when in condition as presented below, sensors' operation
will be distorted.
