4. Connect buzzer (19) to appropriate socket on the control
unit (21) .
5. Connect sensors (20) to appropriate socket on the control
unit (A / B and C / D).
6. Once the signal connection is established, connect to
power. Make a permanent connection using a crimp
connector or by soldering etc.
1. CONTROL UNIT'S POWER: Connect control unit's power
cable plug (18) to appropriate socket on the control unit
(21) (POWER).
2. CAMERA'S POWER SUPPLY: Please note the are two
different methods of connecting the camera to power:
1. insert camera's power cable plug (13) into camera's
power input (12); next connect the red wire (14) to
power (+12 V) eg. reverse light, and black wire (15) to
GND.
2. insert camera's power cable plug (13) into camera's
power input (12) and connect the black wire (15) to
GND. Next connect power wire of the AV cable (5) to
power (12 V) e.g ACC, and connect the power wire of
the AV cable (4) to red wire (14) of the camera's power
supply cable.
1. Monitor
2. Monitor's AV input
3. AV cable plug
4. Power wire of the AV cable
5. Power wire of the AV cable
6. AV cable plug
7. Control unit AV cable input
8. Control unit AV cable connector
9. Control unit AV cable plug
