Owner's manual
routed). Before drilling the holes in vehicle's body, make
sure to select location in which you will not damage any
electrical cables, brake system, fuel tank etc. Also, before
drilling, determine the best way to run the cables through
the vehicle. Ensure the cables does not interfere with any
safety equipment nor reduce safety of the vehicle.
3.
Drill the holes (recommended width of about 10 mm
diameter) behind the license plate frame, right where the
cables will be routed.
4.
After drilling, remove any burs or sharp edges so you do
not damage the cable when pulling it through.
5.
Mount the sensors in the license plate frame.
6.
Carefully route the device's cables through the hole.
7.
Assemble the license plate frame to the license plate bore
on the vehicle with suitable screws. Make sure to assemble
the frame so the camera is at the top of the frame.
8.
Place your license plate into the frame.
Note: It is recommended to implement additional safety
measures to secure the license plate in place (eg. by using
screws) to avoid accidental sliding out of the plate.
connection
Execute all connections before connecting control unit and
camera to power supply:
1.
Connect the control unit AV cable connector (8) to
appropriate socket on the control unit (21) (MONITOR).
2.
Connect AV cable plug (6) to the control unit AV cable
input (7). Next, connect other end of the AV cable (3) into
video input (2) of your vehicle's monitor.
3.
Connect control unit AV cable plug (9) to camera's AV
signal output (10).
16
EN
