Technical Data

Output power RMS / max.
- @ 4 Ohms ..........................................................................1 x 240 / 480 Watts
- @ 2 Ohms ..........................................................................1 x 410 / 820 Watts
- @ 1 Ohm ............................................................................1 x 600 / 1,200 Watts
Amplifier technology .............................................................Class D
Inputs ....................................................................................2 x RCA / Cinch
Input sensitivity .....................................................................RCA / Cinch 0.5 - 6 Volts
Input impedance RCA / Cinch ..............................................20 kOhms
Input impedance highlevel ....................................................13 Ohms
Outputs .................................................................................1 x Speaker output
Frequency response .............................................................10 Hz - 250 Hz
Bass boost ............................................................................0 - 12 dB / 25 - 75 Hz
Lowpass ...............................................................................50 Hz - 250 Hz adjustable
Bandpass..............................................................................10 Hz - 250 Hz adjustable
Subsonic ...............................................................................10 Hz - 50 Hz adjustable
Phase ...................................................................................0 - 180° adjustable
Slope subsonic / lowpass .....................................................12 / 24 dB/Oct.
Signal-to-noise ratio analog input .........................................95 dB (A-weighted)
Distortion (THD) ....................................................................0.20 %
Damping factor .....................................................................100
Operating voltage .................................................................10.5 - 16 Volts (max. 5 sec. down to 6 Volts)
Idle current............................................................................650 mA
Fuse......................................................................................2 x 35 A Maxi-fuse (APX)
Additional features ................................................................ Active, adjustable crossover, bass boost,
Dimensions (H x W x D) .......................................................50 x 230 x 154 mm / 2.00 x 9.06 x 6.06"

Warranty Disclaimer

The limited warranty comply with legal regulations.
Failures or damages caused by overload or im-
proper use are not covered by the warranty. Please
return the defective product only with a valid proof
of purchase and a detailed malfunction description.
Technical specifications are subject to change!
2 x Highlevel speaker input
1 x Remote In
1 x Remote control input
Highlevel 1.1 - 13 Volts
phase shift, Start-Stop capability, highlevel
input with automatic turn on function and
Advanced Diagnostics Error Protection
(ADEP), bass volume cable remote control
Errors are reserved! For damages on the vehicle
and the device, caused by handling errors of the
device, we can't assume liability. These devices are
certified for the use in vehicles within the European
Community (EC).
