2.3.6. Cover suitable for car traffic (B125 in accordance with EN124)
In case of car traffic, an appropriate cover according to EN 124 class B must be used. In
addition, the telescopes must be equipped with a concrete collar. In reference to this, please
see section 3.3.2.
Saphir tank series
700 - 1200
2.3.7. Cover suitable for truck/heavy load traffic (D400 in accordance with EN124)
In case of heavy truck traffic, an appropriate cover according to EN 124 class D must be
used. In addition a load distribution plate must be provided on site (structural drawing
available at GRAF GmbH).
Saphir tank series
max. 9,5 to
700 - 1200
2. Installation conditions
max. 60 to
KLsepa.compact
Diamant tank series
Diamant tank series
max. 60 to
max. 9,5 to
700-910
700-910
