Taurus TF-RUN-X Montage- Und Bedienungsanleitung Seite 23

Nr. Bezeichnung (ENG)
31 TZ04-SP03-0410 Right side stand column welding part
32 TZ04-SP03-0411 Right side handle welding par
33 TZ04-SP03-0401 Right side wall
34 TZ04-SP03-0402 Left side wall
35 TZ04-SP03-0415 Left side support group
36 TZ04-SP03-0407 Right side support group
37 TZ04-SP03-0408 Carry handle
38 M8X25 Carriage bolts
39 M8X16L-N2 Hexagon round screw
40 M10X8t-S2 Nut
41 Φ20Xφ11X1.0t-C1 Washer
42 M10X100L-N1 Hexagon socket cap screws
43 M8X20L-N1 Hexagon socket cap screws
44 M10X60L-N1 Hexagon socket cap screws
45 M10X9t-S1 Lock nut
46 TZ06-SP03-0614 Footing
47 Front wheel
48 M8X50L-N1 Hexagon socket cap screws
49 M16 Footing
50 M16X14.8 Nut
51 6205 One-way bearing
52 8X14 Flat key
53 TZ02-SP03-0236 One-way bearing pedestal
54 M8X55 Carriage bolts
55 TZ-50-0609 Weight interval washer
56 TZ-5013-0211 Small round block
57 M6X14L-N2 Hexagon round screw
58 TZ10-SP03-1002 Foam glues tape
59 Φ9Xφ4.3X0.8t-C1 Washer
60 M4X10L-A1 Cross plate circular bolt
Anz.
1
1
1
1
1
1
1
6
8
2
28
2
16
8
8
2
2
2
2
2
1
1
1
2
1
1
1
4
3
3
23
