Teileliste

Nr. Bezeichnung (ENG)
1 TZ03-SP03-0302 Front axle
2 FL005 Bearing pedestal
3 TZ06-SP03-0612 Front wheel
4 8X25 Flat key
5 M6X8L-J1 Set screw
6 Magnet
7 TZ03-SP03-0303 Back axle
8 TZ06-SP03-0613 Back wheel
9 Running belt unit
10 TZ17-SP03-1701 Running belt
11 TZ10-SP03-1001 Foam glues tape
12 TZ02-SP03-0235 Running belt fixing metal plate
13 Φ10Xφ5.5X1.0t-C1 washer
14 M5X12L-A1 Cross plate circular bolt
15 TZ04-SP03-0403 Running belt rack
16 TZ03-SP03-0308 Small bearing washer sleeve
17 608 Bearing
18 M8X40L-N1 Hexagon socket cap screws
19 Φ16Xφ9X1.0t-C1 washer
20 M8X7t-S1 Lock nut
21 TZ03-SP03-0311 Belt aluminium wheel
22 TZ03-SP03-0309 inner bearing spacing
23 TZ03-SP03-0307 Big bearing washer sleeve
24 M8X45L-N1 Hexagon socket cap screws
25 TZ04-SP03-0414 Left side stand column welding part
26 TZ04-SP03-0414 Left side handle welding part
27 M10X15L-N2 Hexagon round screw
28 Φ22Xφ13X1.5t-C1 Washer
29 M12X30L-N1 Hexagon socket cap screws
30 601 Plastic part
22
Anz.
1
4
2
4
12
2
1
2
60
2
120
120
244
244
1
92
124
92
160
134
14
18
16
14
1
1
7
2
2
2
