13. Technical data

BWT R1 Typ
Nominal connection width DN
Flow rate at Δp =
m³/h
0,2 bar RF after EN 13443-1
Flow rate at Δp =
m³/h
0,5 bar RF after EN 13443-1
Flow rate HWS after EN 1567 m³/h
Output pressure after pressure
bar
reducer
Lower/upper admission width µm
Nominal pressure (PN) bar
Operating pressure, min./max. bar
Water temperature, min./max. °C
Ambient temperature, min./max. °C
Overall length without fitting mm
Overall length with fitting mm
Total hight A mm
Minimum distance pipe centre
B mm
to floor
Connection, diameter C mm
Swivel nut thread G
A
C
16
3/4" RSF 1" RSF 5/4" RSF 3/4" HWS 1" HWS
20 25 32 20 25
3 3,5 4 -
5,0 5,5 6,0 -
- - - 3,05 3,15
- - - 2 - 6 2 - 6
90/110
16
2,5 during the backwash/16
30
40
100 100 105 100 100
186 186 205 198 198
352
350
50
G 1 ¼" G 1 ¼" G 1 ½" G 1 ¼" G 1 ¼"
B
