Starting locomotive operation
GB
Unwrap model: Take the loco carefully out of the
packing with the help of the foil (fig. 1).
Very important!
Before taking into service your model
these bearings of the coupling rods be oiled
as otherwise there would be the risk of bad
running qualities or damage on the locomotive
(see fig. 10).
Operating instructions: Before use is advisable
to let the loco go around about 30 minutes for-
wards and 30 minutes backwards without load, to
obtain an optimal circuit and best tractive power.
The smallest radius this model should run is R2
(358 mm) of the ROCO track system.
4
Your locomotive will run smoothly on clean tracks
only. For this purpose we recommend using item
no. 46400, Roco track cleaning van, or item no.
10002, Roco track cleaning rubber, for remo-
ving heavy dirt.
Fittings: Operation is possible with different cou-
plings (fig. 3). We recommend using the Roco
close coupling.
In the enclosed accessory bag you will find small
kits to be fitted on your locomotive. Please mount
them cautiously.
Attention! Use glue only if indicated (fig. 3).
Running in digital mode: First remove tender
body (fig. 5). Then remove the jumper from the
interface. Finally put the plug of the chip into the
interface as shown in fig. 6.
µ Assembly
Maintenance of the model
GB
To enjoy your locomotive for a long time, it is
necessary to service it regularly (i.e. after it has
been in operation for approximately 30 hours).
Uncouple locomotive and tender first (fig. 2).
1. Cleaning of wheel contacts: Wheel contacts
easily get dirty on tracks which are not entirely
clean. Use a small brush to remove dirt from
spots marked in fig. 9.
µ Assembly
2. Lubrication: Apply tiny oil drops to spots
marked in fig. 10. We recommend using item no.
10906, Roco oiler. For lubrication the gear-parts
(e.g. cog-wheels, worm) we would recommend
our Roco special grease (item No. 10905).
Attention: Please do not oil these parts when
using our grease.
3. Change of lights: (fig. 8).
µ Assembly
4. Steam generator application (fig. 7): First
remove loco and tender body (fig. 4, fig. 5) and
then push in the Seuthe steam generator no. 10
(running in digital mode: use no. 11).
µ Assembly
5. Change of traction tyre: Remove traction
tyre using a pin or a fine screwdriver. When pres-
sing on the new traction tyre please avoid twi-
sting it (fig. 11, fig. 12).
6. Carbon Brush Changing: First remove tender
body (fig. 5), and then the motor (fig. 13).
µ Assembly
Assembly: During assembly please take care of
correct position of contacts.
Off you go!
