The FuelsystemServe has been thoroughly tested before shipping. This guarantee covers all manufacturing
and material defects for 1 year from the delivery date and only covers all parts and labour costs. Shipping
costs will be extra to the customer. This guarantee is not valid if the FuelsystemServe has been tampered
with prior to returning it to Wynn's for inspection or when the Instructions for Use have not been followed.
Damages due to overloading, improper use, application of unauthorised products, shocks, accidents, use
of the machine for other purposes than cleaning and treating are all excluded from the guarantee. The
FuelsystemServe can be locally repaired following written consent by Wynn's Belgium. This consent will be
given after examination of the specific case by Wynn's Belgium. In case of complaint please also send a copy
of the purchase invoice. It is also important to indicate the serial number of the apparatus on the invoice.
1 Pressure gauge to check operating pressure
2 'Low level' indicator
3 On/Off switch
4 Pressure regulator to set pressure
5 Connection blue return hose
6 Connection red pressure hose
7 Fuse
8 Battery clamps
9 Screw cap tank
Cleaning of the housing:
This can be done with non-aggressive and non-abrasive cleaning products.
Fast coupling maintenance:
The O-ring in the fast coupling will age due to the influence of the cleaning liquids and mechanical stress by
the coupling action.
The Machine contains one spare set of O-rings for replacement. O-rings can easily be replaced by
unscrewing the two coupling parts.
Changing the fuse:
Carefully unscrew the cap from the control panel. The fuse comes out of the machine together with the cap.
Change the fuse.
Guarantee

Technical Data

Cleaning & maintenance :
8
2 1
9
3 7 4
8
6 5
