TEIKO BASIC Benutzeranleitung Seite 24

10. additional systems
magic – massage
It is a massage which contains all relaxation features. It combines the hydromassage with air massage by
means of so called Magic nozzles which are installed at the bottom of the bath tub. The hydromassage
bath is switched by depressing the pneumatic or electronic button. The pump compresses the water and
propels it to the distribution tubing. The air is sucked and at the same time regulated by the air auxiliary
suction which is installed on the edge of the bath tub in the form of air valves. The air valves are control-
led by rotating them to the right or to the left. The air is distributed in the parallel tubing with the water.
Through the adjustable nozzles and Magic nozzles the water is mixed with the air and is directed against
the body, both from the bath tub's walls and from the bath tub's bottom which creates the favourable effect of the massage
called Soft Hydro. By means of the three-way valve (item 3.1) the operation of individual sections of nozzles can be set and
changed. By pressing the pneumatic button of airmassage the air bath is switched on. Through suitable setting of three-way
valves the unique effect of the massage which is called Soft Air can be created. The water which springs from the bath tub's
bottom is smashed by the pressure of an air which creates the sparkling effect (this is the softair system and airmassage).
The system is switched off by means of repeated pressing the hydromassage and airmassage buttons . Hydromassage and
sparkling bath can be used simultaneously.
lighting
By pressing the button the halogen lighting is switched on. By repeated pressing the button the halogen
lighting is switched off. This function is accessible only if the bath tub is suffi ciently fi lled with water. Can
be added to the EASY, DUO and DUO-LIGHT systems only.
chromotherapy (colourtherapy – colourful therapy)
Instruction for use: By a short depressing the button (sv) the light source will illuminate with the colour which was used
as the last. By repeated longer depressing of the same button the colourful illumination in various colour combinations will
start. By further short depressing of the button the colour of illumination can be selected. By the fourth depressing the
chromotherapy is switched off.
additional bath heating
By depressing the ON / OFF button the red control lamp illuminates on the controller. This does not indicate that
the heating is switched on, this is in standby position and starts functioning after the given conditions are fulfi lled:
the bath tub is fi lled with a suffi cient quantity of water with the temperature lower than 38°C and the hyd-
romassage bath is on. Additional heating can be added to the EASY, DUO and DUO - LIGHT systems only.
!
Notice:
Heating of cold water is time demanding, the heating is designated for additional water heating only !
aromatherapy
For application of aromatherapy the producer recommends to install the equipment – Aromatherapy which
enables application of aromatherapeutic substances not directly into the water but into the air system.
The advantage of this system is the fact that the aromatherapeutic oils and substances are not in direct
contact with the skin and do not sediment on the bath tub's walls and inside the distribution tubing. Another
advantage is the possibility to change several scent essences during one bath. The aromatherapy is always
connected with one air regulator. Upon opening of this valve the air enriched of aromatherapy substance gets through
underpressure into the water bath.
disinfection - fl ushing (systems without airmassage)
distribution tubing of hydromassage (25 seconds). The distribution tubing of disinfection solution is designed so
as to fl ush entire tubing. After then the interval follows in which the disinfection solution reacts inside the distributi-
on tubing and hydromassage components (60 seconds). After one minute's reaction the electromagnetic valve opens
again and the tubing is fl ushed with clean water (40 seconds). At the systems with airmassage the 60 seconds interval
follows for the water to fl ow off into the drainage tubing. After one minute the compressor starts automatically and
dries up the distribution tubing of the airmassage.
the disinfection system can be started even before starting the massage !!
24
After the water is drained from the hydromassage bath tub by pressing the button (desinfecti-
on) the process of fl ushing and disinfection is activated. The electromagnetic valve is opened
automatically (upon leading to the injector and sucking on the desinfection – 5 seconds). Af-
ter 5 seconds also the second electromagnetic valve with clean water opens automatical-
ly. The disinfection agent and clean water are mixed in the mixer and fl ows further into the
