instruction for use airmassage
Fill the bath tub with water. By pressing the pneumatic button the compressor motor starts. The compressor blows the air
into the distribution tubing. Through the nozzles the air streams against the body which creates the favourable effect of the
massage. By repeated pressing the pneumatic switch the system is switched off. After the water is drained, by repeated
switching on (for about 30 – 120 seconds) the drying and blowing through of tubing can be performed. The compressor
works with the motor speed being pre-set – cannot be regulated. The Apollonia, Antalie, Athina (LUX system ) bath tubs
have the „Water pressure zoning" installed. By means of three-way valve and its positions I, II, III we can prefer the activity
of individual nozzle sections or to select the individual massages.
6. duo
Switching on and off is performed by an electronic controller which is positioned on the upper edge
of the bath tub. Intensity regulation may be performed by means of air regulators.
- electronic controller
- hydroairmassage
system of water pressure regulation by means of nozzle
By rotating the nozzle to the right the water fl ow is regulated to minimum, by rotating to the left
the maximum water fl ows attained. The nozzle's body can be set directionally.
instruction for use
Fill the bath tub with water (cca 3 – 6 cm above the highest nozzle).The recommended water temperature, i.e. the Hyper-
thermal bath is from 37°C to 40°C. By pressing the
the button the cycling switches on – the hydromassage bath will switch on / off in regular intervals. By third depressing
the button the hydromassage bath switches off. The air is brought due to underpressure through the air regulators into
the system which enhances the hydromassage effects.
airmassage
The airmassage is switched on by pressing the
buttons. By repeated pressing the
minimum value to value set by buttons
off. These functions are available only if the bath tub is suffi ciently full with water. The hydromassage and air bath can be
applied simultaneously. After the water is drained from the bath tub, press the
started for 30 seconds which dries the residual water from the tubing system. The Apollonia, Antalie, Athina (LUX system
) bath tubs have the „Water pressure zoning" installed. By means of three-way valve and its positions I, II, III we can prefer
the activity of individual nozzle sections or to select the individual massages.
7. duo light
on the upper edge of the bath tub. Intensity regulation may be performed by means of air regulators.
- electronic controller
- hydroairmassage - hydroairmassage
- lighting
system of water pressure regulation by means of nozzle
By rotating the nozzle to the right the water fl ow is regulated to minimum, by rotating to the left
the maximum water fl ows attained. The nozzle's body can be set directionally.
instruction for use
Fill the bath tub with water (cca 3 – 6 cm above the highest nozzle).The recommended water temperature, i.e. the Hyper-
thermal bath is from 37°C to 40°C. By pressing the
the button the cycling switches on – the hydromassage bath will switch on / off in regular intervals. By third depressing
the button the hydromassage bath switches off. The air is brought due to underpressure through the air regulators into
the system which enhances the hydromassage effects.
hydromassage
regulation of airmassage (to reduce intensity)
airmassage
hydromassage
button, the hydromassage bath will start. By repeated pressing
button. The intensity of airmassage can be set by interrupted pressing of ,
button the cycling is switched on – the intensity of airmassage varies automatically from
, and backwards. By third pressing the
Switching on and off is performed by an electronic controller which is positioned
hydromassage
regulation of airmassage (to reduce intensity)
airmassage
lighting – switched on / off
hydromassage
button, the hydromassage bath will start. By repeated pressing
Three-way valve
button, the compressor of air bath is
Three-way valve
I. - foot nozzles
II. - all nozzles
III. - back nozzles
Air regulation of hydromassage
button the airmassage is switched
I. - foot nozzles
II. - all nozzles
III. - back nozzles
Air regulation of hydromassage
