TEIKO BASIC Benutzeranleitung Seite 19

system of water pressure regulation by means of nozzle
By rotating the nozzle to the right the water fl ow is regulated to minimum, by rotating to the left
the maximum water fl ows attained. The nozzle's body can be set directionally. Electronic control
contains the level safety sensor, which protects the equipment against inadvertent switching on
without fi lled water, through which the pump is protected against its damage.
instruction for use
Fill the bath with water (cca 3 – 6 cm above the highest nozzles). The recommended water temperature, i.e. Hyper thermal
bath is from 37°C to 40°C. By pressing the
water and drives it into the distribution tubing. The air is distributed in a similar way in the parallel tubing. By means of
adjustable nozzles the water is mixed with air and is directed against the body, through which the favourable massage
effect is created. The air is brought due to underpressure through the air regulators into the system which enhances the
massage effects. When depressing the button with
that the pump is automatically switched on/off in about 3 – 4 seconds. By repeated depressing of the
of cycling is switched off. By pressing the
system ) bath tubs have the „Water pressure zoning" installed. By means of three-way valve and its positions I, II, III we can
prefer the activity of individual nozzle sections or to select the individual massages.
4. Windy
Switching on and off is performed by electronic switch which is positioned on the upper edge of the bath tub. Switching on and off is performed by electronic switch which is positioned on the upper edge of the bath tub.
- electronic controller
- airmassage
The system has the non-return valve or the safety loop installed so that the water cannot enter the compressor.
In case of electronic control the system contains the level safety sensor. This protects the system against inadvertent
starting without water being fi lled.
instruction for use
Fill the bath with water. The recommended water temperature, i.e. Hyper-thermal bath is from 37°C to 40°C. By pressing
the electronic button the compressor motor starts.
The compressor propels the air into the distribution tubing. The air fl ows through nozzles against the body, which creates
the favourable effect of airmassage. The system enables regulation of air intake by pressing the
of compressor speed). Pressing the
the maximum compressor speed and vice versa). By repeated pressing the
After the water is drained from the bath tub, press the
dries off the residual water from the system tubing.
5. duo Pneu
on the upper edge of the bath. Intensity regulation may be performed by means of air regulators.
- pneumatic controller
- hydroairmassage
pneumatic switch
of airmassage on / off
!
Notice : In case of pneumatic control the system does not contain the level safety sensor, which
protects the equipment against an inadvertent starting without water being fi lled which could cause
damage of pump. The compressor can be started again after the water is drained from the bath tub (
for about 30 – 120 seconds) to blow off and dry the distribution system.
instruction for use hydromassage
Fill the bath with water (cca 3 – 6 cm above the highest nozzle).The recommended water temperature, i.e. the Hyper-ther-
mal bath is from 37°C to 40°C. By pressing the pneumatic button, the pump motor will start.
The pump compresses the water and drives it into the distribution tubing. The air is distributed in a similar way in the parallel
tubing. By means of rotating nozzles the water is mixed with air and is directed in circle streams against the body, through
which the favourable massage effect is performed. The air is brought through the air regulators into the system which
enhances the massage effects. By repeated pressing the pneumatic switch the system is switched off.
electronic button, the pump motor will start. The pump compresses the
symbol the system is brought into the massage cycling, which means
button the entire system is switched off. The Apollonia, Antalie, Athina (LUX
Airmassage on / off
Airmassage cycling
button initiates the self-cycling of airmassage (from minimum compressor speed to
Switching on and off is performed by a pneumatic switches which are positioned
Three-way valve
Intensity regulation
Intensity regulation
electronic button the system switches off.
button to start for 30 seconds the compressor of air bath which
hydromassage
regulation
button the system
I. - foot nozzles
II. - all nozzles
III. - back nozzles
, buttons (regulation
pneumatic switch
of airmassage on / off
1
