IMPORTANT INFORMATION ON DEF "CRYSTAL LOCKED" ROTORS: DEF
will crystallize almost immediately upon contact with air; if air gets to the DEF in the
rotor cavity, it can crystallize the DEF and lock the rotor in place. If this occurs, the
following procedure will clear the vanes of crystals and return the pump to
operation:
1) Remove the strainer cover
2) Pour de-ionized water into the strainer opening; the DEF crystals will dissolve
instantly.
3) Reinstall strainer cover and torque to 50 inch lbs.
4) Pump at 5 - 10 gallons of DEF through the system to flush the water from the
pump.
Bold text indicates repairs that are not serviceable by the owner; pump must be returned to
the point of purchase for repairs.
If you have questions regarding installing, operating, or servicing your product, please feel
free to contact our Customer Service Department at 1-800-634-2695 (M-F 8 AM–5 PM EST).
You can also reach us on the World Wide Web at "www.tuthill.com".
WARNING! DO NOT open or attempt to repair the motor on your Tuthill pump.
Return it to the place of purchase for service. Opening the motor case can
compromise the integrity of the construction and will void any existing warranty and
certification (UL listing).
Technical Information / Specifications
SV Pump & Motor Features & Specifications
• Inlet: 3/4" BSPP or 1" NPT or 1" BSPP
• Outlet: 3/4" BSPP or 1" NPT or 1" BSPP
• Stainless steel housing, rotor, rotor cover, bypass spring, and motor shaft
• Vanes, seals, and all other non-metallic parts made of approved co-polymer
• Automatic bypass valve
• 60Hz AC - 1/2 HP 115V continuous duty motor with capacitor start
• 50Hz AC - 0.40HP 230V continuous duty motor with capacitor start
• DC - 1/2 HP 12V continuous duty motor
• AC - 115VAC – 60Hz/1Ø or 230 VAC – 50Hz
• DC - 12VDC
• Thermal overload protection and heavy duty switch
