16.2 Check valve
16.3 Spring
16.4 Check valve sleeve 2
16.5 Valve extension
17. Canister
EXTENSION CORD
18. Trigger
19. Flow control knob
20. Quick release lock
21. Shoulder strap hook
22. Sprayer dock
23. On / Off switch
24. Filter
25. Filter cover
26. Viscosity cup
27. Cleaning needle
28. Cleaning brush
29. Spray tip key
30. Air hose
31. Shoulder straps
32. Hose clip
SET - UP
Warning!:
Be sure to use appropriate protective gearand unplug unit.
Warning!:
Make sure area is well ventilated and free off lammable vapors.
FIG. A2
27
26
- 07 -
28
29
32
30
