ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Working width: ............................................40 cm
Cutting height: ................................... 15 – 35 mm
Weight: .......................................................7,5 kg

5. Before starting the equipment

Warning! Wear safety gloves whenever you carry
out any assembly or maintenance work.
5.1 Mower assembly
Fig. 3: Screw the push bar top section (12) to the
two push bar extensions (13). Use the two screws
M6x25 (19) and two hexagonal nuts M6 (20) for
this purpose.
Fig. 4: Screw push bar bottom section A (14),
push bar bottom section B (15) and the two push
bar extensions (13) together. Use four screws size
M6 x 30 (18), two screws size M6 x 25 (19) and
hexagonal nuts size M6 (20).
Fig. 5: First attach one push bar bottom section
to the mower, then press the push bar together
slightly and attach the other side.
5.2 Grass box assembly (Fig. 6 / 7)
A. Push the bar frame into the grass box tube.
B. Snap the side fastening lugs on the grass box
over the bar frame.
C. Snap the bottom fastening lug on the grass
box over the bar frame.
5.3. Attaching the grass box
Attach the assembled grass box to the roller. The
grass box must also be secured to the push bar
using the belt supplied (see Fig. 1).
Anl_GC_HM_40_SPK7.indb 16 Anl_GC_HM_40_SPK7.indb 16
GB

6. Operation

6.1. Adjusting the cutting height (Fig. 8)
Four diff erent cutting heights can be set between
a range of 15 – 35 mm. To do so, pull the spring-
loaded bolts (A) on both sides of out and then
engage them in the required holes.
6.2 Operation
The hand mower can cut grass up to approx. 10
cm in length. If you want your lawn to have a neat,
trimmed look to it, however, you must consistently
keep it cut down to a more manageable height.
When starting the mowing session (and when
mowing over freshly laid sod), it is advisable to
set the cutting height relatively high, then gra-
dually work your way down. For a well-groomed
look, the cutting height should be set to approx.
2.5 cm.
For optimum results, mow your lawn on a weekly
basis. Grass blades grow thicker, faster, and are
more resiliant when their stems are consistently
kept short (unless you live in very dry conditions
and do not frequently water). Always mow the
lawn when it is reasonable dry. In order to ensure
that your lawn has a clean, even look to it when
you're fi nished, mow in fairly straight paths at
walking pace. The cutting swaths should always
overlap each other by a few centimeters in order
to avoid unsightly strips of grass.
7. Cleaning, maintenance and
ordering of spare parts
7.1 Cleaning
•
Clean the machine with a brush or rag after
each use.
•
Store the equipment in a location that is dry
and not accessible by children. For storage in
less space you can remove the grass basket
and move the push bar into a vertically up-
right position (Fig. 10).
•
Keeping your lawn mower in good condition
not only ensures a long lifespan and high per-
formance, but also enables the equipment to
thoroughly cut your grass with minimal effort.
