5.

Operation

⇒ Switch the illumination on (4).
EN
⇒ Select the blasting tank at the selection switch (3) (only on
the 2 tanks version).
Do not operate the foot switch during tank selection.
⇒ Take the handpiece out of the holder of the relevant sandbla-
sting tank (see color markings).
⇒ Activate the foot switch (10, Fig. 1).
♦ The sandblasting material will flow as long as the foot
switch is activated.
5.1

Blasting notes

Flat blasting with wide nozzles:
90003-1739 1,5 x 3,5 mm [0.059 x 0.138 inch]
When blasting glass ceramics, refer to manu facturer's notes.
5.2

Select blasting pressure

⇒ Take the handpiece out of the holder of the relevant sandbla-
sting tank (see color markings).
⇒ Activate the foot switch.
⇒ Set the sandblasting pressure at the pressure regulator (6).
♦ The amount of pressure will be shown on the pressure gau-
ge (7).
Do not exceed the maximum pressure (see „Technical Data").
In the 2 tank version the amount of pressure selected applies
for both blasting tanks.
6.

Cleaning / maintenance

Inside the extractor there are small parts which require maintenance.
Opening the device, other than for the processes described below, is not permissible!
Before cleaning or servicing:
► Switch off and unplug the device!
► Disconnect the appliance from the compressed air supply!
6.1

Clean housing / tanks

⇒ DO NOT use solvent-containing cleaning agents or disinfectants.
⇒ DO NOT use aggressive or abrasive cleaning agents.
⇒ Wipe the housing and aluminium frame gently with a slightly damp cloth, do not apply pressure.
⇒ Wipe out the tanks and lids only with a dry cloth!
4
3
- 10 -
Fig. 7
6 7
Fig. 8
