12. Technical Data

Connection nominal diameter
Connection thread
Limescale protection up to max. 20°dH
Limescale protection capacity
Operating pressure PN
Temperature water inflow max.
Temperature environment max.
Temperature boiler max.
Dimensions of device & connection
dimensions:
Width x height
Fitting length (with screw connections)
Clearance: Wall middle of pipe
Weight
Cable length
Mains connection
Electrical connected rating
Capacity stand-by operation
Energy consumption per m 3 water
Type of protection
* depending on water quality
** country-specific
12
AQA nano
DN 25
outside thread 1"
m 3 /h max. 1.5
l/min. max. 25
l/min. min. 0,6
m 3 max. 110 ± 10*
months max. 12
bar 16
°C 30
°C 40
°C 80
mm 300 x 710
mm 234
mm 80 to 100
kg ca. 11
mm 1000
Volt/Hertz 230/50, 110/60 **
Watt 5.5
Watt 1.8
kWh 0.018
IP 54

13. Technical Drawing

AQA nano
Flow direction left to right
AQA nano
Flow direction right to left
