Axkid Rekid Bedienungsanleitung Seite 7

Rear-Facing 9-18 Kg With ISOFIX
Positioning The Child Restraint
To begin push and hold the adjuster for ISOfix (I). Now you should be able to unfold the ISOfix
2a
arms (H).
The easiest way to lift the Rekid into the vehicle is with its back first. Place the child restraint in
3a
the vehicle with the back of the restraint facing the front of the vehicle.
Note: When installing Rekid in the front seat it is possible, but not crucial, for the back of the restraint to
have contact with the dashboard.
Attaching The Isofix Fittings
The ISOfix brackets are located between the joint of the backrest and base of the vehicle' s
4a
seat.
The supplied ISOfix-guides (U) may assist you in locating these brackets, and they will also help
5a
protecting the vehicle' s upholstery.
Push the ISOfix arms (H) through the guides and clip them onto the brackets. Once there is an
6a
audible click and both indicators (J) are green they are properly secured. To remove the Rekid
child restraint, hold both of the release buttons (M).
To adjust the angle of the child restraint, press the recline adjustment lever (G) to select one of
7a
the three reclining positions. Always choose the most upright position as possible, however
your child must be able to hold their head up on its own, and there should be enough recline to
ensure your child' s head does not fall forward when sleeping. The rule of thumb is that the older the
child grows, the more upright the seat can be installed. Please note that once the installation of the
Rekid is complete, it will be somewhat more reclined as it sinks into the vehicle' s seat from tightening
seat belts and tether straps.
Never install a child restraint in a passenger seat
where an active airbag is fitted.
6
