ITEM DESCRIPTION
Blade access cover Micro
2SQ1
Switch
2SQ2 Stop motor Switch
2SQ3 Start motor Switch
2SA1 Blade cover Micro Switch
2SA2 Hold-down clamp Switch
Start saw blade up-stroke
2SA3 / 2SA4
Switch (2x)
KM1 Contactor for motor
2QM1 Main Power Switch
KM2 Relay for hold-down clamps
KM3 Relay for saw blade up-stroke MY-4-NJ-AC-24V
Temperature Over Load
2ST1
(inside of motor)
Magnetic Valve for hold down
2YV1
clamps
Magnetic Valve for saw blade
2YV2
up-stroke
2TC1 Transformer
2YV3 Spray Mist System
M Motor
2FU1 Fuse
2FU2 Fuse
PE Grounding
EVC-400DGSP Electrical Parts List
TYPE
QK-S-8-1
NPB-22-F01R-O
NPB-22-F10G-1
HE-15G 1318
NPB-22-S201B
NPB-22-F10W-S201B
S-P09-S/AC24V (Shihlin)
ZH-HD-2-80-BY
MY-4-NJ-AC-24V
(Fonray)
(Fonray)
(Lubetool)
23
SPECIFICATION
IP-54 AC-15 14A 250V
AC-15 8A 400V CE
UI 600V IEN 10A
CE
UI 600V IEN 10A
CE
15A 125/250VAC
CE
UI 600V IEN 10A
CE
UI 600V IEN 10A
CE
AC 600V AZ1=1TH=20A
CE
25/16A 250V 7.5HP
400V 3PH CE
5A 240V AC1
5A 28V-DC1 CE
5A 240V AC1 5A 28V-DC1
CE
210MA AC24V 5VA
CE
210MA AC24V 5VA
CE
400V/24V/30AV
4.5~7 bar 24V AC
CE
1.5kW 3Ph 400V 50Hz
1A
6A
