Playing Records - Classic Phono TCD-2500 Benutzerhandbuch

PLAYING RECORDS

This system includes a full-size, 3-speed, belt-drive turntable. You can play 33, 45 and 78 rpm
records.
1) Press the POWER button at the front panel and set the volume to a low level.
2) Press the PHONO button to enter the PHONO mode.
3) Make sure that you have removed the stylus cover from the stylus and have released the
tone arm lock that secured the tone arm to the tone arm rest.
4) Set the turntable speed selector to the appropriate speed 33, 45 or 78 rpm. If you are
playing 45 rpm 'singles', place the 45 rpm adapter on the centre spindle.
5) Place your record on the centre spindle.
6) Raise the cue lever to lift the tone arm off its rest. Move the tone arm to the edge of the
record. The turntable starts automatically. Use the cue lever to gently lower the tone arm
onto the record.
7) Adjust the VOLUME control to the desired level.
8) When the tone arm reaches the end of the record it automatically returns to the tone arm
rest and the record player stops.
9) To turn the system 'off', press the POWER button again and the POWER indicator goes
'off'.
NOTE: Do not turn or stop the turntable manually. Moving or jarring the turntable without
securing the tone arm clamp could result in damage to the tone arm.
IMPORTANT!!
TO PROTECT THE TURNTABLE FROM DAMAGE DURING TRANSPORTATION, A
•
SILVER TRANSIT SCREW IS LOCATED AT THE UPPER RIGHT OF THE TURNTABLE
PLATFORM.
BEFORE PLAYING, PLEASE USE A SCREWDRIVER TO TURN THE TRANSIT SCREW
•
IN CLOCKWISE DIRECTION (SCREW GOING DOWN) COMPLETELY TO UNLOCK
THE TURNTABLE.
TO LOCK THE TURNTABLE AGAIN FOR TRANSPORTATION, PLEASE TURN THE
•
SCREW IN COUNTER-CLOCKWISE DIRECTION.
13
