• Always leave the remote control (transmitter) switched on when the model is in
use. After landing, always switch off the quadrocopter first before you switch off
the remote control.
• Never switch the transmitter off during operation while the quadrocopter is still
running.
• Do not expose the model or the remote control to direct sunlight or excessive heat
for prolonged periods.
• In the event of a severe crash (e.g. from a high altitude), the electronic gyro sen-
sors may be damaged. Always check that the model is functioning properly before
flying it again!
• In the event of a crash, switch off the rotor motors immediately. Rotating rotors
may be damaged if they come into contact with obstacles or in the event of an
impact. Check the rotors for any signs of cracks or damage before flying the model
again!
• To avoid damaging the model due to a crash caused by an undervoltage/over-
discharging of the battery, monitor the undervoltage indicators during the flight.
Battery information
• Batteries present numerous safety hazards.
• Always observe the following general information and safety information when
handling batteries.
• Keep batteries out of the reach of children.
• Do not leave batteries lying around, as they present a choking hazard for children
and pets. Seek immediate medical advice if a battery is swallowed.
• Batteries/rechargeable batteries must never be short-circuited, taken apart or
thrown into fire. Danger of explosion!
• When handling leaking or damaged batteries, always use suitable protective
gloves to avoid burning your skin.
• Do not attempt to recharge disposable, non-rechargeable batteries. This may
cause a fire or explosion! Only charge rechargeable batteries which are intended
for this purpose (1.2 V); use suitable battery chargers. Non-rechargeable batteries
(1.5 V) are designed to be used once and must be disposed of properly when
they are empty.
• Pay attention to the correct polarity when inserting batteries (observe plus/+ and
minus/-). Incorrect polarity will not only damage the transmitter and batteries. It
may also cause a fire or explosion.
• Always exchange the entire set of batteries. Do not mix full batteries with half-full
batteries. Always use batteries of the same type and from the same manufacturer.
• Never mix disposable batteries with rechargeable batteries. Always use dispos-
able batteries to power the remote control.
• If you do not plan to use the model for an extended period (e.g. during storage),
remove the batteries from the remote control to prevent them from leaking and
causing damage.
• Turn the quadrocopter off after a flight and remove the flight battery from the quad-
rocopter. Do not leave the flight battery in the quadrocopter when you are not us-
ing the model (e.g. during transport or storage). This may cause the flight battery
to overdischarge and permanently damage the battery.
• Never charge the flight battery immediately after use. Always leave the flight bat-
tery to cool down until it has reached room or ambient temperature again.
• Charge intact and undamaged batteries only. Do not charge the flight battery if the
external insulation or battery housing is damaged, or if the battery is deformed or
swollen. This may cause a fire or explosion!
• Never damage the external casing of the flight battery. Do not tear the foil cover or
prick the battery with sharp objects. This may cause a fire or explosion!
• Never charge the flight battery when the product is unattended.
• Disconnect the flight battery from the charging cable when the battery is fully
charged.
Disposal
a) Product
Electronic devices are recyclable and should not be disposed of in household waste.
Dispose of the product according to the applicable statutory provisions at the end of
its service life.
Remove any inserted batteries/rechargeable batteries and dispose of them sepa-
rately from the product.
b) Batteries/Rechargeable Batteries
You as the end user are required by law (Battery Ordinance) to return all used batteries/re-
chargeable batteries. Disposing of them in the household waste is prohibited.
Batteries/rechargeable batteries that contain hazardous substances are labelled
with the adjacent icon to indicate that disposal in domestic waste is forbidden. The
descriptions for the respective heavy metals are: Cd = cadmium, Hg = mercury,
Pb = lead (the names are indicated on the battery/rechargeable battery e.g. below
the rubbish bin symbol shown on the left).
You may return used batteries/rechargeable batteries free of charge at the official collection
points in your community, in our stores, or wherever batteries/rechargeable batteries are sold.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declares that this
product complies with directive 2014/53/EU.
The complete text of the EU declaration of conformity is available under the follow-
ing web address:
www.conrad.com/downloads
Choose a language by clicking a flag symbol and enter the order number of the
product into the search field; then you may download the EU declaration of conform-
ity in the PDF format.
Technical Data
a) Remote control
Frequency range ................................................. 2.401 - 2.480 GHz
Transmission power............................................. <20 dBm
Control channels .................................................. 4
Transmitter range ................................................ approx. 30 m
Operating voltage ................................................ 4.5 V/DC via 3x AAA/micro batteries
Dimensions (W x H x D) ...................................... 114 x 95 x 50 mm (without smartphone
Smartphone holder range .................................... max. 80 mm
Weight without batteries ...................................... 70 g
b) Quadcopter
FPV frequency range ........................................... 2.412 - 2.480 GHz
Transmission power............................................. < 20 dBm
Transmitter range ................................................ approx. 30 m
Power supply ....................................................... 3.7 V/220 mAh (1S LiPo)
Dimensions .......................................................... incl. guards: 115 x 115 x 31 mm
Propeller diameter ............................................... 40 mm
Take-off weight, incl. rechargeable battery .......... 31 g
c) Camera
Video resolution ................................................... 1280 x 720 pixels at 30 fps
Image resolution .................................................. 1280 x 720 pixels
Adjustable angle of inclination ............................. 30° - 45°
d) USB charger
Operating voltage ................................................ 5 V/DC (via USB)
Current consumption ........................................... max. 500 mA
Charging time ...................................................... approx. 45 - 60 minutes
e) Software
Android app ......................................................... Android 5.0 or later
iOS app ................................................................ iOS 5.0 or later
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE.
holder)
without guards/propellers: 71 x 71 x 31 mm
folded: 46 x 31 x 62 mm
*1714585_V1_1018_02_VTP_m_short_en
