GENERAL FEATURES.
• Self-diagnosis:
CONTINUOUS and DISCONTINUOUS Transmission mode (CT and DT).
The system runs a diagnostic test (CHECK light blinks twice per second) during the first five seconds after receiver
power-on.
CHECK light blinks once every 2 seconds SYSTEM OK.
CHECK light on steady SYSTEM FAILURE.
• Output commands:
CONTINUOUS Transmission mode (CT).
Relay T12 (START) is activated at the press of T12
(START) on the transmitter.
Relay T1 (Stop) is active when the radio connection
between transmitter and receiver is active. Relay T1 (Stop)
is protected by fuse F1 (6.3A).
MOTHER bOARD DIP SWITCH: DIP1 OFF - DIP2 OFF.
• Indicator lights:
CONTINUOUS and DISCONTINUOUS Transmission mode (CT and DT).
POWER LIGHT indicates the system is powered on.
STATUS LIGHT blinks once per second to indicate that radio connection is active.
LEARN LIGHT provides indications when in programming mode.
• External antenna option:
CONTINUOUS and DISCONTINUOUS Transmission mode (CT and DT).
bring the external antenna cable to cable gland M16 which you will have prepared previously. Connect the external
antenna to the connector on the radio module; do not force the connection. Tighten the cable gland on the largest
diameter cable only.
• Terminal block and wiring.
CONTINUOUS and DISCONTINUOUS Transmission mode (CT and DT).
Maximum useful cross-section area 2.5 sq mm. For wiring connections, follow the mother board layout and the wiring
examples provided in ANNEX and any documents attached to this manual.
DISCONTINUOUS Transmission mode (DT).
Relay T12 is activated at the press of T12 on the transmitter.
Relay T1 is activated at the press of T1 on the transmitter.
Relay T1 is protected by fuse F1 (6.3A).
MOTHER bOARD DIP SWITCH: DIP1 ON – DIP2 OFF.
