ENGLISH
to be connected must be able to provide the
maximum amount of electrical power required by
the product.If it cannot do this, contact an electrician
for appropriate remedial action.
• Specifications for
correspond to the electrical data on data plate A
(fig.1).
1
the power supply
A

Structure and equipment

(Fig.2).
1. Control Panel Cover
must
2. Control Panel
3. Remote Control
4. Front Body
5. Rear Body
6. Side Supports
7. Front Cover
8. Rear Cover
9. Base
10. Power Cable
2
rear
1
2
3
4
5
6
7
8
9
front
10
13
