e. Projector DMX start address selection
All DMX-controlled devices need a digital start address so that the correct device responds to the signals. This digital
start address is the channel number from which the device starts to "listen" to the DMX controller. Enter the correct
number and read it from the display located on the base of the VDP250MHS13.
You can use the same starting address for a whole group of devices or enter an individual one for every device.
When all devices have the same address, all the units will "listen" to the control signal on one particular channel. In
other words: changing the settings of one channel will affect all devices simultaneously. If you set different
addresses, each device will "listen" to a separate channel number. Changing the settings of one channel will only
affect the device in question.
In the case of the 13-channel VDP250MHS13, you will have to set the start address of the first unit to 1, the second
unit to 14 (1 + 13), the third to 27 (14 + 13), and so on.
f. Control Board Operation

FUNCTION TABLE:

Mode
Pan movement in positive or negative direction
PAN
Vertical movement in positive or negative direction
TILT
Addr DMX address setting
rESET Reset
Rainbow colour wheel change colour linear or stepping
COLI
Working mode
RUN
LAMP Lamp switch
VEr Software version
HEAT Lamp hot
Lamp error
LA.Er
CONTROL BOARD OPERATION:
1. Select working mode by pressing MODE.
2. Press ENTER to confirm the selection.
3. Press UP and DOWN to select working condition.
4. Press ENTER to confirm the selection.
7. Cleaning and Maintenance
1. All screws should be tightened and free of corrosion.
2. The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension, trussing)
should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting supports, do not
change the location of the connections ...
3. Mechanically moving parts must not show any signs of wear and tear.
4. The electric power supply cables must not show any damage. Have a qualified technician maintain the device.
5. Disconnect the device from the mains prior to maintenance activities.
6. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
7. There are no user-serviceable parts, apart from the lamp and the fuse (see "Installation").
8. Contact your dealer for spare parts if necessary.
VDP250MHS13
Function
6
Condition
YES – negative direction
YES – negative direction
YES - reset
YES - linear
OFF – DMX 512 mode
PR – Automatic
SLAE – Slave mode
ON – Lamp ON
OFF – Lamp OFF
