Use And Operation - Klarstein 10029294 Anleitung

Control Panel (both items)
START Press to turn unit on.
STOP Press to turn unit off.
SELECT Ice size selection (S)
Small or (L) Large. ) The
default setting is Large.
ADD WATER If this comes on press
STOP, add water and
press START to restart
the Ice maker.
ICEFULL If this light comes on
the ice has reached the
maximum capacity of
the storage cabinet.
Before first Use
• During transportation, the incline angle of the cabinet should not be over 45°. Do not turn the Ice maker
upside down,as this may damage the compressor and sealed system.
• Remove all packing material and carefully check your ice maker to ensure it is in good condition and that
there is no damage to the ice maker or power cord and plug.
• The ice maker should be placed horizontally on a level surface.To ensure proper ventilation for your ice ma-
ker allow 150 mm of space at the top, the back and on each side. Do not install the Ice maker near an oven,
radiator, or any other heat source. Before using the Ice maker for the first time, please wait 2 hours after
positioning it, and keep the front lid open for at least 2 hours
• Ensure that the voltage indicated on the ice maker corresponds with the voltage in your home.
• Pure water is not allowed to be used on this unit, spring water is recommended.
Operation
1. If filling water by manual (10029294), take
out of the ice basket,then add water to the
tank directly,please make sure the water is not
over the MAX line. If filling water automatically
(10029295),connect the external water pipe at
back of unit with the water tape as follows.
2. Plug in.
3. Select desired ice cube size by pressing "SELECT". Note: Please select the (S) when ambient temperature is
below 15 °C.
9

Use and Operation
