Slope function

EN
To activate the slope function, you must position the device, paralell to the slope plane.
You can do this by using the plumb point (7) and a laserline.
•
Turn the unit on, and wait untill it is levelled.
• To activate the slope function, press the on/off switch for a few seconds untill the
middle LED turns red.
5sec
• BEWARE: Only the horizontal, and the front vertical laserline are visible.
• BEWARE: If you want to use a laser receiver, activate this function by pressing the
outdoor button first. You have to do this before setting a slope.
• BEWARE: If you want to set a 90° angle, please do this before activating the slope
function.
• When the slope function (manual mode) is activated, the LED's next to "H" and "V"
turns green. These LED'S indicate the first axe. (X-axe)
•
To adjust the slope, hold button "H" or "V". Keep doing this untill the correct slope is
obtained.
46 Multicross 8 High Precision Super Vision
V
H
4 Horizontal 4 Vertical
On/O Outdoor
Multicross 8 HPSV
041.08
H V
4 Horizontal 4 Vertical
On/O Outdoor
Multicross 8 HPSV
041.08
H
4 Horizontal 4 Vertical
On/O Outdoor
Multicross 8 HPSV
X 041.08
V
