System design RK-4

AF
MMR1
KF1 KF2
KKP1
RLF1
Boiler 1 Boiler 2
AF Outside temperature sensor
BUS Remote control connection
DKP Unmixed circuit pump
KF Boiler sensor
KKP Boiler circuit pump
KSPF Solar calorifier sensor
KVLF Solar panel flow sensor
MKP Mixer circuit pump
MM Mixer motor
MMR Mixing valve motor return temperature raising
RLF Return sensor
SF DHW sensor
SLP Calorifier loading pump
SVF Total flow sensor
VA Variable output
VE Variable input
VF Flow sensor
ZP DHW circulation pump
12
VF2
MKP2
MM2
VF2 VF1
MKP2 MKP1
MM2 MM1
SVF
MMR2
SLP
KKP2
RLF2
VF2
MKP2
MM2
DKP
SF SF
SLP SLP
Buffer of Buffer or
air heater air heater
KVLF
DKP DKP
SF ZP
KSPF
VA2
Buffer
