1 SQUELCH - 0-9

At the value 0, the squelch function is off. The higher the number,
the stronger the signal has to be to unmute the speaker for the
signal to be audible.
2 POWER - LOW/HIGH
Please note: with the TeCom-DB-C, only the LOW tx power is
available due to governmental regulations.
LOW: 0.5 W
HIGH: VHF (5 W) / UHF (4 W)
3 SCAN MD - CO / TO / SE
The available channel scan modes are:
TO : Time-Operated-Scan
The scan pauses for a certain time on an occupied channel and
then continues regardless if a signal is present or not.
CO : Carrier-Operated-Scan
The scan pauses as long as a signal is present. Once the
signal ceases, the scan will be continued.
SE : Search-Scan
The scan function stops on an occupied channel. The radio
remains on the first channel where a signal has been detected.
4 LAMP MD - AUTO / ON / OFF
The settings for the background light are:
AUTO : the LCD light is automatically turned on after pushing a key
ON : the LCD light is constantly on
OFF : the LCD light is constantly off
5 KEYLOCK - MANUAL / AUTOMAT
Once keylock is activated, only the PTT key (13), the emergency call
key (12) and the On/Off switch (2) are active. All other keys are
locked. The keylock mode is indicated by the key symbol, located in
the bottom right corner.
MANUAL : activate/deactivate the keylock by pressing the
STD key [STD] (10).
AUTOMAT : the keylock function is automatically activated,
30 seconds after the last entry. To deactivate the
automatic keylock mode, press the STD key [STD] (10).
14
6 TOT - OFF / 30 - 270 s in 30-seconds-steps
The Time-Out-Timer function restricts the transmission time in the
range of 30-270 seconds in 30-second-steps.
7 VOX LVL - OFF/ LEVEL 9
Setting of the VOX sensitivity. On level 1 (lowest sensitivity), the
signal has to be the strongest to start signal transmission.
8 R CTCSS - OFF / 01-50
CTCSS receipt code (see page 66)
9 T CTCSS - OFF / 01-50
CTCSS transmission code (see page 66)
10 COLOUR LIGHT 1 / 2 / 3
background light: 1 = light blue / 2 = deep blue / 3 = green
11 STEPS - 5 / 6.25 / 10 / 12.5 / 25 kHz
Please note: this function is only available in the HAM version -H.
12 BEEP - ON / OFF
13 WID/NAR - WIDE / NARROW
Please note: in the -C version, only the narrow bandwidth
(NARROW, 12.5 kHz) is available.
14 OPN MSG - OFF / DC VOLT / MESSAGE
The greeting message is displayed when turning the radio on.
OFF : no text
MESSAGE : „WELCOME"
DC VOLT : actual battery current level in Volts
15 BCLO - OFF / Carrier / CT/DQT
Transmission Blockage on occupied channels
OFF : blockage off
Carrier : blockage with signal carrier
CT/DQT: blockage with CTCSS/DCS codes
16 CH.MDF - CHANNEL / NAME / FREQ.CH / FREQ
Please note: the display option FREQ. is only available in the -H
version.
CHANNEL : channel number
NAME : channel name, as programmed
FREQ.CH : channel number and frequency
FREQ. : channel frequency
17 CH.NAME (channel name) - ^, _, -, `, a-z, A-Z , /,0-9, :, ;, <, =, >, ?, @, [, ]
A max. of seven symbols can be used; switch with the A/B key [A/B] (8)
to the next digit and confirm your entry with the menu key [MENU] (6).
