order codes

4116 = Universal transmitter
4501 = Display / programming front
5910 = CjC connector

Electrical specifications

Specifications range .................................... -20°C to +60°C
Common specifications:
Supply voltage, universal ............................ 21.6...253 VAC,
Max. consumption....................................... ≤ 2.5 W
Fuse ............................................................. 400 mA SB / 250 VAC
Isolation voltage, test / operation ............... 2.3 kVAC / 250 VAC
Communications interface .......................... Programming front 4501
Signal / noise ratio ...................................... Min. 60 dB (0...100 kHz)
Response time (0...90%, 100...10%):
Temperature input ................................... ≤ 1 s
mA / V input ............................................ ≤ 400 ms
Calibration temperature............................... 20...28°C
Accuracy, the greater of the general and basic values:
Input
type
All
Input
type
mA
Volt
Pt100
Linear resistance
Potentiometer
TC type:
E, J, K, L, N, T, U
TC type: R, S, W3,
W5, LR
TC type: B
160...400°C
TC type: B
400...1820°C
42
General values
Absolute
accuracy
≤ ±0.1% of span
Basic values
Basic
accuracy
≤ ±4 µA
≤ ±20 µV
≤ ±0.2°C
≤ ±0.1 Ω
≤ ±0.1 Ω
≤ ±1°C
≤ ±2°C
≤ ±4.5°C
≤ ±2°C
or 19.2...300 VDC
Temperature
coefficient
≤ ±0.01% of span / °C
Temperature
coefficient
≤ ±0.4 µA / °C
≤ ±2 µV / °C
≤ ±0.01°C / °C
≤ ±0.01 Ω / °C
≤ ±0.01 Ω / °C
≤ ±0.05°C / °C
≤ ±0.2°C / °C
≤ ±0.45°C / °C
≤ ±0.2°C / °C
