Front Panel

1
Standby button:
On/Off
2
Display:
The 2x16 LCD displays preset names and parameter
values
3
Up Arrow:
Press to navigate through the user interface
4
Down Arrow:
Press to navigate through the user interface
5
Left Arrow:
Press to navigate through the user interface
6
Right Arrow:
Press to navigate through the user interface
4
1 2
Stereo
802III
7
Select/Load:
Loads presets and selects utility mode
8
Channel 1 Signal LED:
Illuminates green to show input level
9
Channel 1 Clip LED:
Illuminates red to show input clipping
10
Channel 2 Signal LED:
Illuminates green to show input level
11
Channel 2 Clip LED:
Illuminates red to show input clipping
12
Removable rack ears
3 7 8 9
4 10
5 6
11 12
