Assembly and Operating Instructions
70mm Ø5mm
24

Installation VC410-II

1) Turn the screws on the housing into posi-
tion 0 and remove the cover.
2) Secure the surfacetype housing on the
wall using 4 screws. Make sure the screws
are suitable for use with the given type of
wall.
3) Penetrate the cable entry diaphram using
a suitable cylindrical tool. When inserting
the connecting cable, ensure that it sits
securely in the diaphram.
4) Now connect the VC420II using the ter-
minal connecting plan in chapter "Installa-
tion" as a guide.
When carrying out installation work, al-
ways ensure that the connecting cable
and the antenna are not damaged or
crushed.
Attention
