Outputs
Connect the drive to the outputs of the device. The arrows on the device indicate
the running direction of the drive.
Light
A bridge connection between L and the encoding terminal
time to be increased from 120 seconds (
Venetian blind
A bridge connection between L and the encoding terminal
lows the receiver to be controlled in momentary command mode.
Press and hold the control command button for more than 1 second
to move the blind in maintainedcommand mode. The running time is
180 seconds instead of 120 seconds with roller shutters.
Individual inputs
These terminals are available for an additional return switch. If you press one of
the up or down buttons of the maintained switch for more than 0,5 seconds, the
blind/shutter will move automatically in the chosen direction to the final position.
If you touch it for less than 0,5 seconds, the blind/shutter will move and stop
again immediately.

Explanations

Centronic VarioControl VC420-II
4034 200 221 0
IP 20
230 V/50 Hz
Ind.
Ind.
) to infinity ( ).
allows the running
al-
