Tire inspection
1
2
1. Tire tread depth
2. Tire sidewall
3. Tire wear indicator
The tires must be checked before each
ride. If a tire tread shows crosswise lines
(minimum tread depth), if the tire has a
nail or glass fragments in it, or if the
sidewall is cracked, have a
dealer replace the tire immediately.
Minimum tire tread depth (front and
rear):
Front : 1.6 mm
Rear: 1.6mm
3
NOTE:
The tire tread depth limits may differ
from country to country. Always comply
with the local regulations.
Tire information
This scooter is equipped with cast
wheels and tubeless tires with valves.
Operating the scooter with exces-
sively worn tires decrease riding sta-
bility and can lead to loss of control.
Please replace the excessive worn tires
by Explorer dealer immediately.
Brakes, tires, and related wheel parts
replacement should be left to a
Explorer Ser vice Technician.
6-9
Front tire:
Explorer
Size:
3.50 -10 51J (For 10" Wheel Rim)
100 / 60-12, 45J (For 12" Wheel Rim)
Manufacturer/model:
KENDA / K-324
CHENG SHIN / C-6031R(12" RIM)
Rear tire:
Size:
3.50 -10 51J (For 10" Wheel Rim)
100 / 60-12, 45J (For 12" Wheel Rim)
Manufacturer/model:
KENDA / K-324
CHENG SHIN / C-6031R(12" RIM)
(10" RIM)
(10" RIM)
