Replacing a headlight bulb

1
1. Headlight
This model is equipped with halogen
bulb headlight .If a headlight bulb bur
-ns out,have a Explorer dealer replac
-e it and, if necessary,adjust the hea
-dlight beam.
Front turn signal lights
1
2

1. Front turn signal light

2. Screw
PERIODIC MAINTENANCE AND MINOR REPAIR
If the turn signal light bulb does not co
-m on,remove the screw out and repla-
ce the bulb.
Replacing rear turn signal light
bulb
1. Turn signal light bulb
1.Remove the turn signal light lens
2.Remove the burnt-out bulb by push
-ing it in and turning it counterclockw
-ise.
3.Insert a new bulb into the socket,pus
-h it in ,and then turn it clockwise unt
-il it stops.
4.Install the lens.
6-19
Tail/brake light and licenes light
1
1. Tail/brake light
2. Licenes light
If the tail/brake light and licenes light bulb
does not come on,have a Explorer dealer
check its electrical circuit or replace the
bulb.
EAU10122
1
2
