Controls and instruments

1
2
3
23.Rear brake lever (page 3-4)
24.Left handlebar switches (page 3-3) 4
25.Speedometer unit (page 3-2)
26.Fuel gauge (page 3-3)
27.Right handlebar switches (page 3-3)
5
28.Front brake lever (page 3-4)
29.Throttle grip (page 6-11)
30.Main switch/steering lock (page 3-1)
6
31.Hook,Helmet (page 3-10)
7
23 24 25 26
31
2-3
DESCRPTION
27
28
29
30
