INSTALLATION
Front panel
8
1
7
POWER
1
PLAY/PAUSE
2
STOP
3
SKIP
4
EJECT
5
Remote Sensor
6
Disc in
7
8
Reset
Rear panel electrical connection
Yellow VideoOut
White AudioOut
Red AudioOut
Digital Out
3
2
Turn the power on/off
Begin disc play/Pause disc play (
playback DVD discs,press the PLAY button of
the Remote Controller)
Stop disc play
Use to skip a scene or music
A disc is ejected by this button
Receives a light signal from the remote controller
A disc is inserted here
Resetting the processor
26
5
6
4
Note
:To start
Yellow Video in
White Audio In
Red Audio In
External Remote Sensor
Connect DC 12V po
Input from DC 12V power
from AC/DC Adapter
EXTERNAL REMOTE
w
er cable
source
